Die Cast Zinc Festo Suction Cup Complete VASB-55-1/4-PUR-B 1396063 GTIN4052568062026

Product Categories

YIKANG AUTOMATION

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Brand Name : FESTO

Model Number : VASB-55-1/4-PUR-B

Place of Origin : China

MOQ : 1pc

Price : EXW USD20-30

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000 pcs per month

Delivery Time : 7-10working days

Packaging Details : Plastic bag, Carton

Type : VASB-55-1/4-PUR-B

Part no : 1396063

Brand : FESTO

Vacuum connection : G1/4

Product weight : 39 g

Material screw-in stud : Die-cast zinc

Contact Now

FESTO Suction cup complete VASB-55-1/4-PUR-B 1396063 GTIN4052568062026

About product

1.Wide range to suit applications with various temperature ranges and workpiece surfaces.

2.Suction cups made from silicone are food-safe.

3.All tubing connection sizes correspond to a holder size.

Technical Data

Height compensator for suction cup	20 mm
Nominal size	4 mm
Suction cup diameter	55 mm
Position of connection	Top
Mounting position	optional
Symbol	00991485
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-A1-L
Holding force at nominal operating pressure	110 N
Product weight	39 g
Type of mounting	Via vacuum port
Vacuum connection	G1/4
Colour	Blue
Material screw-in stud	Die-cast zinc
Note on materials	RoHS-compliant
Material suction cup	PUR

General technical data
